PRECISION DORMER高速钢锥柄麻花钻

PRECISION DORMER 高速钢锥柄麻花钻

右旋·118°钻尖角

应用：

·普通用于钻削不同的钢，铸铁和其他含铁不含铁金属和合金

·普通的118°钻尖角适合许多钻削应用和加工条件

·锥柄放入标准莫氏锥柄套内

·用于有莫氏锥度套的便携或固定加工机床上

·为达效果及延长刀具寿命建议在多数钻削操作时要求使用适当的切削/润滑油和冷却液

特点：

·右旋切削

·标准的2刃设计

·通常的118°钻尖角

·标准莫氏锥柄对应钻头直径

·槽与长度成比例

技术参数：

·高速钢材质

·一般负载，一般用途钻削

·氧氮化发黑处理

*有限库存

货号	型号	尺寸	直径	刃长	全长	刃数	重量	价格(1件起订)			购买
								1	1	1
01-318-412		1-3/4"		10-3/8"	16-1/4"	2	3.475 kg	5108.48	5108.48	5108.48
01-318-408		1-11/16"		10-1/8"	15-3/4"	2	3.328 kg	5194.47	5194.47	5194.47
01-318-404		1-5/8"		10"	15-5/8"	2	3.165 kg	4681.01	4681.01	4681.01
01-318-400		1-9/16"		9-5/8"	15-1/4"	2	2.97 kg	4317.35	4317.35	4317.35
01-318-398		1-17/32"		9-3/8"	15"	2	2.867 kg	4059.67	4059.67	4059.67
01-318-380		1-1/4"		7-7/8"	12-1/2"	2	1.399 kg	2420.13	2420.13	2420.13
01-318-376		1-3/16"		7-3/8"	12"	2	1.271 kg	2079.56	2079.56	2079.56
01-318-372		1-1/8"		7-1/8"	11-3/4"	2	1.178 kg	1880.80	1880.80	1880.80
01-318-356		7/8"		6-1/8"	10"	2	0.574 kg	1086.80	1086.80	1086.80
01-318-352		13/16"		6-1/8"	10"	2	0.531 kg	1003.89	1003.89	1003.89
01-318-351		51/64"		6-1/8"	10"	2	0.52 kg	1062.17	1062.17	1062.17
01-318-336		9/16"		4-7/8"	8-1/4"	2	0.223 kg	531.44	531.44	531.44
01-318-335		35/64"		4-7/8"	8-1/4"	2	0.217 kg	559.11	559.11	559.11
01-318-334		17/32"		4-5/8"	8"	2	0.207 kg	487.05	487.05	487.05
01-318-333		33/64"		4-5/8"	8"	2	0.202 kg	522.92	522.92	522.92
01-317-398		1-17/32"		9-3/8"	16-3/8"	2	2.268 kg	3514.76	3514.76	3514.76
01-317-396		1-1/2"		9-3/8"	15"	2	1.814 kg	2976.32	2976.32	2976.32
01-317-394		1-15/32"		9-1/4"	14-7/8"	2	1.814 kg	3007.24	3007.24	3007.24
01-317-389*		1-25/64"		9"	14-5/8"	2	1.814 kg	2840.26	2840.26	2840.26
01-317-388		1-3/8"		8-7/8"	14-1/2"	2	1.361 kg	2505.91	2505.91	2505.91
01-317-384		1-5/16"		8-5/8"	14-1/4"	2	1.361 kg	2369.85	2369.85	2369.85
01-317-380		1-1/4"		7-7/8"	13-1/2"	2	1.134 kg	1915.09	1915.09	1915.09
01-317-376		1-3/16"		7-3/8"	13"	2	0.907 kg	1658.23	1658.23	1658.23
01-317-374		1-5/32"		7-1/4"	12-7/8"	2	0.907 kg	1608.76	1608.76	1608.76
01-317-372		1-1/8"		7-1/8"	12-3/4"	2	0.907 kg	1559.28	1559.28	1559.28
01-317-370		1-3/32"		6-7/8"	12-1/2"	2	0.862 kg	1481.93	1481.93	1481.93
01-317-368		1-1/16"		6-5/8"	11-1/4"	2	0.816 kg	1293.27	1293.27	1293.27
01-317-367		1-3/64"		6-5/8"	11-1/4"	2	0.771 kg	1413.83	1413.83	1413.83
01-317-366		1-1/32"		6-1/2"	11-1/8"	2	0.771 kg	1222.11	1222.11	1222.11
01-317-365		1-1/64"		6-1/2"	11-1/8"	2	0.726 kg	1348.85	1348.85	1348.85
01-317-364		1"		6-3/8"	11"	2	0.726 kg	1126.21	1126.21	1126.21
01-317-363		63/64"		6-3/8"	11"	2	0.68 kg	1191.10	1191.10	1191.10
01-317-362		31/32"		6-3/8"	11"	2	0.68 kg	1098.34	1098.34	1098.34
01-317-360		15/16"		6-1/8"	10-3/4"	2	0.68 kg	1030.31	1030.31	1030.31
01-317-359		59/64"		6-1/8"	10-3/4"	2	0.68 kg	1110.71	1110.71	1110.71
01-317-358		29/32"		6-1/8"	10-3/4"	2	0.68 kg	1073.60	1073.60	1073.60
01-317-357		57/64"		6-1/8"	10-3/4"	2	0.68 kg	1104.52	1104.52	1104.52
01-317-356		7/8"		6-1/8"	10-3/4"	2	0.68 kg	1030.31	1030.31	1030.31
01-317-355		55/64"		6-1/8"	10-3/4"	2	0.68 kg	1085.97	1085.97	1085.97
01-317-354		27-32"		6-1/8"	10-3/4"	2	0.68 kg	993.20	993.20	993.20
01-317-353		53/64"		6-1/8"	10-3/4"	2	0.68 kg	1061.23	1061.23	1061.23
01-317-352		13/16"		6-1/8"	10-3/4"	2	0.68 kg	937.54	937.54	937.54
01-317-351		51/64"		6-1/8"	10-3/4"	2	0.68 kg	1030.31	1030.31	1030.31
01-317-350		25/32"		6"	9-7/8"	2	0.68 kg	925.17	925.17	925.17
01-317-349		49/64"		6"	9-7/8"	2	0.68 kg	956.09	956.09	956.09
01-317-348		3/4"		5-7/8"	9-3/4"	2	0.454 kg	723.98	723.98	723.98
01-317-347		47/64"		5-7/8"	9-3/4"	2	0.454 kg	753.04	753.04	753.04
01-317-346		23/32"		5-5/8"	9-1/2"	2	0.454 kg	678.21	678.21	678.21
01-317-345		45/64"		5-5/8"	9-1/2"	2	0.454 kg	717.79	717.79	717.79
01-317-344		11/16"		5-3/8"	9-1/4"	2	0.454 kg	643.58	643.58	643.58
01-317-343		43/64"		5-3/8"	9-1/4"	2	0.454 kg	696.15	696.15	696.15
01-317-342		21/32"		5-1/8"	9"	2	0.454 kg	623.79	623.79	623.79
01-317-341		41/64"		5-1/8"	9"	2	0.454 kg	659.04	659.04	659.04
01-317-340		5/8"		4-7/8"	8-3/4"	2	0.454 kg	575.55	575.55	575.55
01-317-339		39/64"		4-7/8"	8-3/4"	2	0.454 kg	612.04	612.04	612.04
01-317-338		19/32"		4-7/8"	8-3/4"	2	0.454 kg	568.74	568.74	568.74
01-317-337		37/64"		4-7/8"	8-3/4"	2	0.454 kg	591.63	591.63	591.63
01-317-336		9/16"		4-7/8"	8-3/4"	2	0.454 kg	539.68	539.68	539.68
01-317-335		35/64"		4-7/8"	8-3/4"	2	0.454 kg	566.89	566.89	566.89
01-317-334		17/32"		4-5/8"	8-1/2"	2	0.454 kg	507.52	507.52	507.52
01-317-333		33/64"		4-5/8"	8-1/2"	2	0.454 kg	533.49	533.49	533.49
01-317-332		1/2"		4-3/8"	8-1/4"	2	0.454 kg	470.41	470.41	470.41
01-317-330		15/32"		4-1/8"	7-1/2"	2	0.108 kg	354.77	354.77	354.77
01-317-329*		29/64"		4-1/8"	7-1/2"	2	0.104 kg	342.24	342.24	342.24
01-317-328		7/16"		3-7/8"	7-1/4"	2	0.097 kg	309.77	309.77	309.77
01-317-327		27/64"		3-7/8"	7-1/4"	2	0.093 kg	318.42	318.42	318.42
01-317-326		13/32"		3-5/8"	7"	2	0.087 kg	279.92	279.92	279.92
01-317-324		3/8"		3-1/2"	6-3/4"	2	0.08 kg	274.97	274.97	274.97
01-317-323*		23/64"		3-1/2"	6-3/4"	2	0.077 kg	278.68	278.68	278.68
01-317-322*		11/32"		3-1/4"	6-1/2"	2	0.073 kg	252.39	252.39	252.39
01-317-321		21/64"		3-1/4"	6-1/2"	2	0.07 kg	248.83	248.83	248.83
01-317-320		5/16"		3-1/8"	6-3/8"	2	0.067 kg	185.28	185.28	185.28
01-317-319		19/64"		3-1/8"	6-3/8"	2	0.065 kg	231.35	231.35	231.35
01-317-317		17/64"		3"	6-1/4"	2	0.061 kg	189.60	189.60	189.60
01-317-316		1/4"		2-7/8"	6-1/8"	2	0.059 kg	171.36	171.36	171.36
01-317-315*		15/64"		2-7/8"	6-1/8"	2	0.057 kg	189.60	189.60	189.60
01-317-314		7/32"		2-3/4"	6"	2	0.056 kg	166.25	166.25	166.25
01-317-312		3/16"		2-1/2"	5-3/4"	2	0.053 kg	153.73	153.73	153.73
